Waypoint R3
The Waypoint R3 is a high-precision GIS terminal with ±2cm GNSS accuracy, a 5.5-inch sunlight-readable screen, IP68 rating, 4G connectivity, and a professional surveying keyboard, built for extreme conditions and applications like forestry, cadastral surveying, and railway construction.
High-Precision Positioning & Data Processing
1. Triple-frequency GNSS board supports GPS, BeiDou, GLONASS, Galileo, QZSS, and IRNSS, enabling centimeter-level accuracy (static ±2cm) via PPP technology.
2. 2.0GHz octa-core industrial processor with DDR4 RAM (64GB ROM + 4GB RAM) ensures efficient processing of complex geographical data for smooth GIS operations.
Industrial-Grade Durability & Portable Design
1. IP68 waterproofing, military-grade shock resistance, and 1.5m drop protection ensure reliability in harsh environments.
2. Ultra-thin body with an integrated Corti professional surveying keyboard optimizes one-handed operation, while the 5.5-inch 1080P IPS screen delivers clear visibility under direct sunlight.
Long Battery Life & High-Speed Connectivity
1. 9000mAh battery supports up to 16 hours of continuous operation, with 4G global connectivity (including North America/Canada) enabling high-speed data transfer.
2. 2W 120dB speaker ensures clear communication in noisy environments, complemented by RS232 and Bluetooth interfaces for device expansion.
Specifications
System
Operating system | Android 10 gms |
CPU | octa-core 2.0 GHz |
RAM | 4 GB SDRAM |
Flash memory | 64 GB |
Memory card | MicroSDHC up to 256 GB |
Physical
Size (L × W × H) | 226.3*90.6*16.9 |
Environment | Operating: -20°C to +65 °C (-4°F to +149°F) Storage: -30°C to +70°C (-22°F to +158°F) |
Dust and water proof | IP68 |
Humidity | 5% ~ 95% (non-condensing) |
Display | 5.5" IPS LTPS LCD capacitive multi-touch 1920 × 1080 pixels HD+ 401 ppi Brightness 500 nit |
Keypad | Corti key |
RTK GNSS
Constellation | BDS: B1I, B1C, B2a, B2b（PPP), B3I, B1I, B2I； GPS：L1 C/A, L1C*, L2, L5； GLO：G1, G2； GAL：E1, E5a, E5b, E6； QZSS: L1C/A, L1C, L2, L5, L6； NavIC: L5; SBAS: L1 C/A; |
RTK Accuracy | 1cm + 1ppm |
SPP Accuracy | 1.5m |
PPP Accuracy | 20cm@Static |
Communications
SIM Card Type | Nano-SIM card Dual SIM, Single Standby |
Network modem | GSM: 850/900/1800/1900 WCDMA: B1/B2/B4/B5/B8 LTE-TDD: B34/B38/39/B40/B41 LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12 /B13/B17/B20/B25/B26/B28/B66 |
Wi-Fi | 802.11 a/b/g/n/ac access point mode (2.4 G / 5G) |
Bluetooth® | 5.0 |
USB | Type C, OTG supported |
NFC | Support |
